Industrial Manufacturing
Heavy-Duty Floors Built for Manufacturing Plants
PumaCRETE urethane concrete floors take the daily punishment of industrial manufacturing — forklifts, dropped tooling, hot oils, thermal shock, and aggressive wash-downs — and keep performing for 20+ years.
From metal fabrication and automotive plants to chemical processing, food and beverage, and ESD-controlled electronics manufacturing, PumaCRETE delivers a seamless, monolithic surface that resists impact, chemicals, and continuous high-traffic abuse. Installed in 24–72 hours with phased rollouts that keep your production lines running.
20+ yrs
Service Life
248°F
Heat Resistant
24–72 hr
Minimum Installation Time
12 mils–1/2 in.
System Thickness
The Engineering Advantage
Why Urethane Concrete Outperforms Epoxy in Manufacturing
Epoxy floors crack under thermal shock and delaminate under continuous heavy loading. Urethane concrete was engineered specifically for the abuse industrial plants deliver every shift.
Impact & Abrasion Proof
Dropped tooling, pallet corners, steel wheels, and constant forklift traffic don't chip or gouge a 3/8-inch PumaCRETE topping. The system is roughly 3× harder than standard concrete.
Thermal Shock Resistant
Steam cleaning, hot oil spills, and process heat up to 248°F won't crack or delaminate the floor. Coefficient of thermal expansion closely matches concrete — no debonding cycles.
Chemical & Oil Resistant
Hydraulic fluids, cutting oils, coolants, acids, caustics, and solvents wipe clean. The seamless, non-porous surface prevents penetration and substrate contamination.
Fast Return-to-Service
Foot traffic in 6 hours, full forklift loading in 24 hours after final coat — at 70°F. Phased installation keeps adjacent production zones running during the rebuild.
Slip-Resistant in Wet Conditions
Aggregate broadcast is tuned to your environment — fine for assembly cleanrooms, coarse for oily metal-finishing bays — to meet OSHA slip-resistance requirements.
Seamless & Hygienic
No joints, grout lines, or cracks for debris and bacteria to collect in. Coved-up walls and integral drains create a true cleanable surface that meets USDA and HACCP standards.
Full Product Line
Every Floor Category PumaCRETE Offers
Industrial manufacturing is the largest of several specialty categories we serve. Each category below maps to a dedicated floor system — engineered for the loads, chemicals, and compliance demands of that industry.
Industrial & Manufacturing
Heavy-duty urethane concrete and polymeric finishes for metal fabrication, automotive, plastics, chemical processing, and general heavy manufacturing.
Manufacturing Floors →
ESD & Conductive — Overview
Static-dissipative and conductive systems for facilities where electrostatic discharge is a process, product, or safety risk.
ESD-Conductive Floors →
Electronics Manufacturing
ESD epoxy and urethane floors for semiconductor, PCB assembly, and electronics production environments where static damages product.
Electronics Mfg Floors →
Munitions & Explosives
Conductive epoxy systems engineered for Arms, Ammunition & Explosives (AA&E) areas where static discharge is a life-safety hazard.
Munitions / Explosives Floors →
Data Centers
Anti-static epoxy floors for server halls, network operations centers, and switching rooms. Protects sensitive equipment and supports raised-floor systems.
Data Center Floors →
AGV & Robot Areas
Smooth, flat, durable floors with optional ESD properties — engineered for AGV and Robot pathways in warehouses and modern fulfillment centers.
AGV / Robot Floors →
Food & Beverage — USA
USDA/FDA-compliant urethane concrete for U.S. food processing plants. Steam-cleanable, slope-to-drain, slip-resistant, and antimicrobial options.
USA Food & Beverage Floors →
Food & Beverage — Caribbean
Tropical-climate-rated food and beverage flooring for Caribbean processors. Engineered for high humidity, hot wash-downs, and salt-air exposure.
Caribbean F&B Floors →
Food & Beverage — Central America
Central American food and beverage installations. Bilingual project management and shipping-included programs for regional processors.
Central America F&B Floors →
Food & Beverage — South America
South American food and beverage processing floors. Full export programs covering Brazil, Argentina, Chile, Colombia, Peru and surrounding markets.
South America F&B Floors →
USPS Workrooms (401-ECO)
Specialty heavy-duty screed system developed for USPS workroom floors. Fast turnaround, government-spec compliant, and proven over decades of service.
USPS / 401-ECO →
Coatings, Color & Specifications
Color charts, MasterFormat specifications, technical data sheets, prep & application guides, tool kits, and SDS documents for every PumaCRETE system.
Resources Library →
Performance Data
Technical Specifications
Independently tested performance data for the standard 3/8-inch PumaCRETE 300-series urethane concrete system used in industrial manufacturing applications.
| Compressive Strength | 9,500 psi (ASTM C579) | Tensile Strength | 1,450 psi (ASTM C307) |
| Flexural Strength | 3,200 psi (ASTM C580) | Bond Strength to Concrete | > substrate (ASTM D7234) |
| Abrasion Resistance | 0.06 g loss (ASTM C501) | Impact Resistance | >160 in-lb (ASTM D2794) |
| Service Temperature | -40°F to 248°F | Thermal Shock | Pass — boiling to ambient cycles |
| Coefficient of Friction | 0.6–0.9 wet (tunable) | VOC Content | < 50 g/L |
| System Thickness | 1/4 in. / 3/8 in. / 1/2 in. | USDA / FDA Compliance | Yes — incidental contact |
Product Line
Choosing the Right PumaCRETE Series for Your Plant
Thickness and finish should match the actual service load — over-spec is wasted budget, under-spec is early failure. The five PumaCRETE product families cover everything from light dry-environment coatings to severe-service screed-applied mortars.
| Series | Thickness | Best For | Finish |
|---|---|---|---|
| 100 / 200 Series | 12–60 mils (0.012–0.060 in.) | Light-to-medium duty, dry environments — foot, cart, occasional power-lift traffic | Satin to gloss, customized texture |
| 300 Series | 1/16 to 1/4 inch | Heavy-duty manufacturing — metal fab, automotive, plastics, chemical, wet/damp areas | Trowel-textured, broadcast aggregate, customizable |
| 400 Series | 1/4 to 3/4 inch | Severe service — forging, foundry, steel mill, heavy impact zones. One-pass trowel application. | Matte/flat, optional wax for gloss |
| 401-ECO | 1/4 to 1/2 inch | USPS workrooms and government projects requiring fast turnaround and proven durability | Trowel-applied screed, low-odor |
| Puma-ESD Series | 12 mils to 1/4 inch | Electronics, AGV/Robot, munitions/AA&E, data centers — conductive (C) or static-dissipative (SD) | Satin to semi-gloss, ANSI/ESD S20.20 compliant |
See the full System Comparison | Color Charts | MasterFormat Specifications.
NATIONWIDE NETWORK OF INSTALLATION
With a nationwide network of installers, PumaCRETE® has provides a tradition of quality. Our factory-trained installation crews can provide turn-key installation and localized service. In many cases, we can train your personnel or local contractor, with on site training available.
PumaCRETE® SITE TRAINERS
PumaCRETE® can provide on site trainers, along with detailed installation instructions and videos, specialty tools, and surface prep guidelines for new installers or DIY installation. See our installation page for our application resources.
How We Work
The PumaCRETE Installation Process
A predictable five-stage process built around your production calender. Phased zones, dust-contained surface prep, and overnight cure windows keep production losses to a minimum.
1
Site Assessment
Moisture testing, substrate evaluation, drainage and slope review, chemical exposure audit. We specify the right system for your actual conditions.
2
Surface Preparation
Diamond grinding or shot blasting to CSP 4–5 profile. Crack and joint repair. HEPA-vacuumed — no airborne dust migrating to adjacent rooms.
3
Drainage & Coving
Slope-to-drain corrections, new drain installation, and integral 4 to 6-inch cove base placed before the wear topping.
4
Topping Application
One-pass troweled PumaCRETE 401-HF at 1/4-inch (or 3/8-inch for severe thermal). Optional aggregate broadcast and pigmented seal coat.
5
Cure & Return-to-Service
Foot traffic at 6 hours, light wheeled traffic at 12 hours, full forklift and CIP service at 24 hours after the final coat (at 70°F).
Audit-Ready Compliance
Compliance & Industry Standards
PumaCRETE systems meet or exceed the standards required for regulated manufacturing environments — and we provide the documentation your auditors need.
Safety & OSHA
- OSHA 1910.22 — walking-working surfaces slip resistance
- ANSI A1264.2 — coefficient of friction for industrial floors
- NFPA fire-retardant formulations available
- Low-VOC chemistry — installation in occupied facilities
Hygiene & Food-Adjacent
- USDA-accepted for incidental food contact zones
- FDA 21 CFR 175.300 compliant formulations
- HACCP-friendly seamless & coved installations
- Antimicrobial additive options for biological control
Electronics & ESD
- ANSI/ESD S20.20 static-dissipative systems
- 10⁶ to 10⁹ ohm resistance range — tunable
- Compatible with grounded workstation infrastructure
- Munitions / AA&E conductive systems available
Environmental & LEED
- Contributes to LEED MR & IEQ credits
- 20+ year service life reduces lifecycle waste
- Low-VOC during installation and in service
- Cleanable surface — reduced cleaning chemical use
Lifecycle Economics
The Real Cost of a Manufacturing Floor
Up-front price per square foot is the wrong number to optimize. Total cost of ownership over 20 years — including downtime, repairs, and replacement — is where PumaCRETE wins decisively.
| Cost Factor | Bare Concrete | Epoxy Coating | PumaCRETE Urethane Concrete |
|---|---|---|---|
| Typical Service Life | 5–10 yrs (with patching) | 3–7 yrs | 20+ yrs |
| Up-Front Cost (per sq ft) | $2–$5 | $4–$8 | $8–$15 |
| 20-Year Total Cost (per sq ft) | $15–$30 (multiple repairs/replace) | $20–$40 (2–4 replacements) | $8–$15 (single install) |
| Production Downtime | High — frequent patching | Medium — recoat every 3–5 yrs | Minimal — one phased install |
| Thermal Shock Tolerance | Cracks & spalls | Delaminates | Withstands cycling |
| Chemical Resistance | None — substrate stains | Moderate — surface damage | Excellent — sealed, wipeable |
| Cleanability | Porous, retains contaminants | Joints & chips trap debris | Seamless, hygienic |
30+ Years of Experience
Why Manufacturers Choose PumaCRETE
Urethane concrete is only as good as the installation crew putting it down. PumaCRETE has 30+ years of experience and a nationwide network of factory-certified applicators — and it shows.
Specification Engineering
We don’t sell a single product — we specify the right system for your loads, chemicals, and temperatures. Wrong spec is the #1 cause of premature failure.
Production-Aware Scheduling
We work nights, weekends, plant shutdowns, and phased bays. Your output target drives our schedule — not the other way around.
Factory-Certified Crews
A nationwide network of certified applicators trained directly on PumaCRETE chemistry. No subcontracting to general flooring teams who learn on your floor.
Dust-Contained Surface Prep
HEPA-shrouded grinders and shot blasters mean no airborne silica or debris migrating into adjacent production zones.
Documented QA/QC
Moisture readings, mil-thickness verification, slip-resistance testing, photo documentation. Full close-out package for your audit file.
30+ Years of Experience
Three decades of urethane concrete installations across manufacturing, food and beverage, government, ESD, and AGV/Robot environments — proven across every category.
The Bottom Line
What You Get with a PumaCRETE Manufacturing Floor
A short, honest summary of the operational outcomes — written for plant managers and EHS leads who need to justify the investment.
- 20+ year service life under continuous heavy-duty manufacturing conditions — verified by independent ASTM testing and 30+ years of field performance.
- Zero unplanned downtime for floor failures, patching, or joint repair across the warranty period.
- 24–72 hour install windows per zone, scheduled around your production calendar — phased rollouts keep adjacent lines running.
- OSHA-compliant slip resistance in wet, oily, or dry conditions — aggregate tuned to your specific work environment.
- USDA, FDA, and HACCP compliance for food-adjacent manufacturing and pharmaceutical zones.
- ESD/static-dissipative options for electronics, munitions, AGV/Robot, and data-center environments — ANSI/ESD S20.20 compliant.
- Seamless, monolithic surface — no joints to clean, no grout to fail, no edges for forklift tires to chip.
- Full chemical resistance to hydraulic oils, cutting fluids, coolants, acids, caustics, and most industrial solvents.
- Documented QA close-out package — mil-thickness, slip-resistance, moisture, and photo records for your audit and insurance files.
- Nationwide certified applicator network — backed by 30+ years of PumaCRETE experience in industrial urethane concrete flooring.
Frequently Asked Questions
Industrial Manufacturing Floors FAQ
Properly installed PumaCRETE urethane concrete floors deliver a 20+ year service life under continuous heavy-duty manufacturing use, including forklift traffic, dropped tooling, and aggressive cleaning cycles. Real-world installations from the early 2000s are still in service today with no resurfacing.
Yes. PumaCRETE bonds directly to sound, properly prepared concrete substrates. We diamond-grind the existing slab to a CSP 4–5 profile, repair cracks and spalls, and apply the urethane concrete system at 1/4 to 3/8 inch thickness depending on service conditions. The bond strength typically exceeds the tensile strength of the underlying concrete itself.
Most manufacturing zones are completed in 24–72 hours per bay. Phased installation lets production continue in adjacent areas, and we routinely work nights, weekends, and plant shutdown windows. At 70°F, the floor accepts foot traffic in 6 hours, light wheel loading in 12 hours, and full forklift loading within 24 hours of the final coat.
Yes. PumaCRETE resists continuous service temperatures up to 248°F and thermal shock from steam cleaning to boiling water without cracking, delaminating, or losing chemical resistance. The coefficient of thermal expansion closely matches concrete, so the system doesn't debond during heat cycling — the failure mode that destroys epoxy floors.
PumaCRETE resists hydraulic fluids, cutting oils, coolants, acids, alkalis, and most industrial solvents. The seamless surface prevents penetration into the substrate, so spills wipe clean without staining or substrate damage. For aggressive chemical service — concentrated acids, strong solvents — we specify a containment-grade variant with documented exposure ratings.
Yes. Aggregate broadcasts can be tuned to deliver OSHA-compliant slip resistance in wet or oily areas — coefficient of friction from 0.6 to 0.9. The seamless, non-porous surface meets USDA, FDA, and HACCP requirements for food-adjacent manufacturing zones, and integral coving plus slope-to-drain installations support full wash-down cleaning protocols.
EXPERIENCE AND EXPERTISE
Ready to Specify Your Manufacturing Floor?
Get a no-obligation site assessment and system specification from PumaCRETE — 30+ years of experience and a nationwide network of factory-certified applicators. We’ll review your loads, chemicals, temperature profile, and production schedule — and deliver a written spec and budget within five business days.
